Data transmission
Firewall throughput
2.3 Gbit/s
VPN throughput
0.81 Gbit/s
Performance
Heat dissipation
82.23 BTU/h
Noise level
41.5 dB
Mean time between failures (MTBF)
529688 h
Network
Number of VPN connections
500
Concurrent SSL/VPN connections (maximum)
150
VPN tunnels quantity
300
Number of VLANs
64
Security
VPN support
IKEv2, IPSec, SSL, L2TP/IPSec
Management features
URL filtering
Yes
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
Ethernet LAN (RJ-45) ports
7
Number of console ports
1
SFP module slots quantity
1
Design
Rack mounting
Yes
Form factor
1U
Built-in fan
Yes
Power
Input current
4.17 A
Power consumption (max)
24.1 W
Certificates
Certification
DCC, CE, C-Tick, LVD
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-30 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
10 - 90%
Weight & dimensions
Width
300 mm
Depth
188 mm
Height
44 mm
Weight
1.65 kg
Packaging data
Package width
351 mm
Package height
152 mm
Package depth
245 mm
Package weight
2.83 kg
Packaging content
Rack mount kit
Yes
Other features
Firewall throughput
2300 Mbit/s
VPN throughput
810 Mbit/s
