Management features
Switch type
Managed
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
16
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Network
Broadcast storm control
Y
Auto MDI/MDI-X
Y
MAC address auto-learning supported
Y
Data transmission
Switching capacity
32 Gbit/s
MAC address table
8000 entries
Jumbo frames support
Y
Jumbo frames
10000
Security
DHCP features
DHCP snooping
Design
Stackable
Y
Product colour
Black
Housing material
Metal
LED indicators
Power, Speed
DIN rail mounting
Y
Country of origin
Taiwan
Certification
FCC, CE, RoHS, REACH
Performance
Harmonized System (HS) code
8517.62.0020
Technical details
Master (outer) case GTIN (EAN/UPC)
10037332266986
Power
Power supply included
Y
DC input voltage
12 - 60 V
Input current
1.5 A
Power consumption (typical)
12 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
N
Operational conditions
Operating temperature (T-T)
-10 - 60 °C
Storage temperature (T-T)
-40 - 85 °C
Operating relative humidity (H-H)
5 - 95%
Weight & dimensions
Width
50 mm
Depth
119.9 mm
Height
160 mm
Weight
910 g
Packaging data
Package width
232.9 mm
Package depth
182.9 mm
Package height
62 mm
Package weight
1.05 kg
Logistics data
Master (outer) case width
334 mm
Master (outer) case length
384 mm
Master (outer) case height
260.1 mm
Master (outer) case gross weight
11.6 kg
Products per master (outer) case
10 pc(s)
