Management features
Switch type
Managed
Switch layer
L2
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity
4
Power connector
Terminal block (6-pin)
Network
Networking standards
IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
10G support
Y
Full duplex
Y
Auto-negotiation
Y
MAC address auto-learning supported
Y
Data transmission
Switching capacity
24 Gbit/s
MAC address table
16000 entries
Jumbo frames support
Y
Jumbo frames
10000
Design
Rack mounting
Y
Stackable
N
Product colour
Black
Housing material
Aluminium
LED indicators
Activity, Link, Power, Power fail
DIN rail mounting
Y
Country of origin
Taiwan
Performance
Fanless
Y
Harmonized System (HS) code
8517.62.0020
Technical details
Sustainability compliance
Y
Sustainability certificates
CE, RoHS, REACH
Master (outer) case GTIN (EAN/UPC)
10037332266955
Power
Power supply included
N
DC input voltage
24 - 57 V
Input current
6 A
Power consumption (typical)
18 W
Power consumption (max)
258 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Y
Power over Ethernet plus (PoE+) ports quantity
8
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
240 W
Operational conditions
Operating temperature (T-T)
-40 - 75 °C
Storage temperature (T-T)
-40 - 85 °C
Operating relative humidity (H-H)
5 - 95%
Operating altitude
0 - 2000 m
Weight & dimensions
Width
50 mm
Depth
119.9 mm
Height
160 mm
Weight
980 g
Packaging data
Rack mount kit
Y
Package width
232.9 mm
Package depth
182.9 mm
Package height
62 mm
Package weight
1.19 kg
Logistics data
Master (outer) case width
334 mm
Master (outer) case length
384 mm
Master (outer) case height
260.1 mm
Master (outer) case gross weight
12.7 kg
Products per master (outer) case
10 pc(s)
