40G MTP/MPO TO 4XLC FAN-OUT OM4 PLENUM-RATED FIBER OPTIC CABLE 4

Introduction

The one-meter N845-01M-8L-MG MTP/MPO to 8xLC Fan-Out Patch Cable supports 40 Gb Ethernet speeds and is designed for high-density connections between 40GBASE-SR4 network equipment. With one male MTP/MPO and eight male LC connectors, this OM4-rated multimode fiber optic fan-out cable supports various multi- and single-fiber connections. It fully transmits 40GBASE-SR with four fibers transmitting at 10 Gbps in each direction. Base-8 Fiber compatible with both QSFP+ 40GBASE-SR4 and QSFP28 100GBASE-SR4 connections.

Push/pull tab connectors are easily accessible in high-density data center applications and make the cable easy to install and remove with one hand. The magenta-colored N845-01M-8L-MG features a premium-grade ceramic ferrule for 10 GbE and faster applications. The slim, space-saving uniboot design makes cable easier to manage. The plenum-rated jacket is perfect for connecting high-speed network components in ceilings, walls and ducts. The sturdy plastic housing is built to last a long time.

OM4-Rated for 40 Gb Ethernet Applications
Connects 4 10Gb duplex LC devices to a 40Gb MTP port on a network switch
Designed for high-density connections between 40GBASE-SR4 network equipment
Base-8 Fiber compatible with both QSFP+ 40GBASE-SR4 and QSFP28 100GBASE-SR4 connections
Multimode fiber optic fan-out cable supports various multi- and single-fiber connections
Fully transmits 40GBASE-SR with four fibers transmitting at 10 Gbps in each direction
Magenta-colored for identification as an OM4 cable

MTP/MPO and LC Connectors with Push/Pull Tabs
1 male MTP/MPO and 8 male LC connectors
Push/pull tab connectors easy to install and remove with one hand

Error-Free Signal Transfer
Premium-grade ceramic ferrule for 10 GbE and faster applications
Slim, space-saving uniboot design makes cable easier to manage
Plenum-rated jacket for connecting in ceilings, walls and ducts
Sturdy plastic housing built to last a long time

Features

Cable length

1 m

Connector 1

MPO/MTP

Connector 2

8x LC

Connector 1 gender

Male

Connector 2 gender

Female

Fibre optic type

OM4

Product colour

Black, Magenta, Turquoise

Core diameter

50 µm

Cladding diameter

125 µm

Fiber mode structure

Multi-mode

Data transfer rate

100 Gbit/s

Connector material

Ceramic

Country of origin

China

Harmonized System (HS) code

8544.70.0000

Technical details

Sustainability certificates

RoHS

Master (outer) case GTIN (EAN/UPC)

10037332200041

Operational conditions

Operating temperature (T-T)

-20 - 60 °C

Storage temperature (T-T)

-20 - 60 °C

Packaging data

Package width

177.8 mm

Package depth

228.6 mm

Package height

12.7 mm

Package weight

40 g

Logistics data

Master (outer) case width

147.3 mm

Master (outer) case length

188 mm

Master (outer) case height

99.1 mm

Master (outer) case gross weight

500 g

Products per master (outer) case

10 pc(s)
