Management features
Switch type
Managed
Switch layer
L2/L3/L4
Quality of Service (QoS) support
Yes
Web-based management
Yes
System event log
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
48
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity
2
SFP module slots quantity
2
Network
Networking standards
IEEE 802.1D, IEEE 802.1as, IEEE 802.1s, IEEE 802.1v, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T
Port mirroring
Yes
Full duplex
Yes
IP routing
Yes
Flow control support
Yes
Broadcast storm control
Yes
Spanning tree protocol
Yes
VLAN support
Yes
Number of VLANs
256
Data transmission
Switching capacity
100 Gbit/s
MAC address table
16000 entries
Store-and-forward
Yes
Number of queues
8
Number of static routes
32
Jumbo frames support
Yes
Security
DHCP features
DHCP client
Access Control List (ACL)
Yes
IGMP snooping
Yes
Security algorithms
802.1x RADIUS, HTTPS, SSL/TLS
MAC address filtering
Yes
SSH/SSL support
Yes
Multicast features
Multicast support
Yes
Number of multicast groups filtered
512
Protocols
Management protocols
SNMP v1/v2
Supported network protocols
IP
Design
Rack mounting
Yes
Product colour
Black, Grey
LED indicators
Activity, Link, Power
Performance
Noise level
37.2 dB
Firmware upgradeable
Yes
Mean time between failures (MTBF)
390728 h
Power
AC input voltage
100 - 240 V
Power consumption (typical)
41.1 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
0 - 90%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Non-operating altitude
0 - 3000 m
Weight & dimensions
Width
440 mm
Depth
257 mm
Height
43 mm
Weight
3.46 kg
Packaging content
Cables included
AC
Manual
Yes
Certificates
Certification
CE, FCC, VCCI, EN, C-Tick, CCC, CSA, UL/cUL, IEC
