Microchip’s PD9524-10GC is a six ports Power over Ethernet midspan offering 60W power per port according to the IEEE 802.3bt standard. The PD-95XX-10GC family is available in 6, 12 and 24 port configurations. Input power is provided through a universal AC voltage connector. The product is designed for use with a standard 10/100/1000 and 10G BaseT Ethernet network over a standard category 6A or better cabling plant, according to the IEEE 802.3bt standard. The PD-9524-10GC incorporates power management through Microchip’s PowerView Pro software allowing the user to monitor and control the midspan via a remote network management station.
2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet
10,100,1000 Mbit/s
Yes
IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Power
CE,WEEE
24
Yes
100 V
950 W
100 - 240 V
50 - 60 Hz
12 A
60 W
0 - 40 °C
32 - 104 °F
0 - 90%
-20 - 70 °C
0 - 95%
271 mm
435 mm
44 mm
5.48 kg
CE, WEEE
85044095
