Processor
Processor manufacturer
Intel
Processor model
6353P
Processor base frequency
2.7 GHz
Processor family
IntelŽ XeonŽ
Processor cores
8
Processor socket
LGA 1700
Processor threads
16
System bus rate
16 GT/s
Processor operating modes
64-bit
Performance cores
8
Processor boost frequency
5.4 GHz
Processor cache
24 MB
Thermal Design Power (TDP)
65 W
Package type
Tray
Maximum number of DMI lanes
8
Processor codename
Raptor Lake
Processor ARK ID
241608
Memory
Maximum internal memory supported by processor
128 GB
Memory types supported by processor
DDR5-SDRAM
Memory clock speeds supported by processor
4800 MHz
Memory channels
Dual-channel
ECC
Yes
Graphics
On-board graphics card
No
Discrete graphics card
No
On-board graphics card model
Not available
Discrete graphics card model
Not available
Features
Execute Disable Bit
Yes
Idle States
Yes
Thermal Monitoring Technologies
Yes
Market segment
Server
Use conditions
Server/Enterprise
Maximum number of PCI Express lanes
20
PCI Express slots version
5.0
PCI Express configurations
2x8+1x4, 1x16+1x4
Supported instruction sets
AVX 2.0, SSE4.1, SSE4.2
Scalability
1S
CPU configuration (max)
1
Embedded options available
No
Processor special features
IntelŽ Hyper Threading Technology (IntelŽ HT Technology)
Yes
IntelŽ Turbo Boost Technology
2.0
IntelŽ AES New Instructions (IntelŽ AES-NI)
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel Trusted Execution Technology
Yes
IntelŽ Turbo Boost Max Technology 3.0 frequency
5.1 GHz
IntelŽ Turbo Boost Technology 2.0 frequency
5.4 GHz
IntelŽ Transactional Synchronization Extensions
No
IntelŽ Total Memory Encryption
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
IntelŽ Secure Key
Yes
IntelŽ OS Guard
Yes
Intel 64
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel Turbo Boost Max Technology 3.0
Yes
IntelŽ Boot Guard
Yes
Mode-based Execute Control (MBE)
Yes
IntelŽ Optane DC Persistent Memory Supported
No
IntelŽ Virtualization Technology with Redirect Protection (VT-rp)
Yes
Microprocessor PCIe Revision
Gen 5
IntelŽ Total Memory Encryption - Multi Key
Yes
Operational conditions
Tjunction
100 °C
Technical details
Launch date
Q1'25
Memory speed (max)
4800 MHz
Other features
Maximum internal memory
128 GB
