Introduction
IntelŽ AES New Instructions (IntelŽ AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
IntelŽ Trusted Execution Technology for safer computing is a versatile set of hardware extensions to IntelŽ processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.
IntelŽ vPro Technology is a set of security and manageability capabilities built into the processor aimed at addressing four critical areas of IT security: 1) Threat management, including protection from rootkits, viruses, and malware 2) Identity and web site access point protection 3) Confidential personal and business data protection 4) Remote and local monitoring, remediation, and repair of PCs and workstations.
Technical details
Servicing status
ESU Notification Issued
End of servicing updates date
Sunday, December 31, 2023
Launch date
Q3'17
Processor cache
14080 KB
Product type
Processor
Status
Launched
Maximum memory
768 GB
Processor brand name
Intel Xeon Silver
Intel Xeon Silver Processor
Supported memory types
DDR4-SDRAM
Last change
63903513
Product family
Intel Xeon Processors
IntelŽ Speed Shift Technology version
1.00
IntelŽ Volume Management Device (VMD) version
1.00
Memory speed (max)
2400 MHz
Mode-based Execute Control (MBE) version
1.00
Number of UPI links
2
Processor
Processor manufacturer
Intel
Processor generation
1st Generation IntelŽ XeonŽ Scalable
Processor model
4114T
Processor base frequency
2.2 GHz
Processor family
Intel Xeon Silver
Processor cores
10
Processor socket
FCLGA3647
Component for
Server/workstation
Processor lithography
14 nm
Processor threads
20
Processor operating modes
64-bit
Processor boost frequency
3 GHz
Processor cache
13.75 MB
Processor cache type
L3
Thermal Design Power (TDP)
85 W
Box
N
Cooler included
N
Bus type
UPI
Processor codename
Skylake
Processor ARK ID
126153
Memory
Maximum internal memory supported by processor
768 GB
Memory types supported by processor
DDR4-SDRAM
Memory clock speeds supported by processor
2400 MHz
Memory channels
Hexa-channel
ECC
Y
Graphics
On-board graphics card
N
Features
Execute Disable Bit
Y
Market segment
Server
Maximum number of PCI Express lanes
48
PCI Express slots version
3.0
Supported instruction sets
SSE4.2,AVX,AVX 2.0,AVX-512
Scalability
2S
Embedded options available
Y
PCI Express CEM revision
3.0
Harmonized System (HS) code
8542310001
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
G077159
Processor special features
IntelŽ Hyper Threading Technology (IntelŽ HT Technology)
Y
IntelŽ Turbo Boost Technology
2.0
IntelŽ AES New Instructions (IntelŽ AES-NI)
Y
Enhanced Intel SpeedStep Technology
Y
Intel Trusted Execution Technology
Y
IntelŽ Speed Shift Technology
Y
IntelŽ Transactional Synchronization Extensions
Y
Intel VT-x with Extended Page Tables (EPT)
Y
Intel TSX-NI
Y
Intel 64
Y
Intel Virtualization Technology (VT-x)
Y
Intel Virtualization Technology for Directed I/O (VT-d)
Y
Intel TSX-NI version
1.00
Conflict-Free processor
Y
Intel Turbo Boost Max Technology 3.0
N
IntelŽ Optane Memory Ready
N
AVX-512 Fused Multiply-Add (FMA) units
1
IntelŽ Volume Management Device (VMD)
Y
Mode-based Execute Control (MBE)
Y
IntelŽ vPro Platform Eligibility
Y
Operational conditions
Tcase
92 °C
Weight & dimensions
Processor package size
76mm x 56.5mm
Other features
Maximum internal memory
768 GB
Maximum internal memory
786432 MB
