Processor
Processor cache type
L3
Processor boost frequency
3.4 GHz
Processor cores
16
Processor manufacturer
Intel
Processor family
Intel Xeon Silver
Processor model
4514Y
Processor frequency
2 GHz
Processor boost frequency
3.4 GHz
Processor cores
16
Processor cache
30 MB
Number of processors installed
1
Memory
Memory slots
32x DIMM
Maximum internal memory
8 TB
Internal memory
128 GB
Internal memory type
DDR5-SDRAM
Memory slots
32x DIMM
Memory clock speed
5600 MHz
Memory layout (slots x size)
4 x 32 GB
Maximum internal memory
8 TB
Storage
Maximum storage capacity
583.3 TB
SSD interface
PCI Express 4.0
RAID support
Yes
SSD interface
PCI Express 4.0
Supported RAID controllers
HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device
Maximum storage capacity
583.3 TB
RAID support
Yes
Optical drive type
No
Ports & interfaces
Expansion slots
Up to 8 PCIe Gen5, and 2 OCP 3.0, for detailed descriptions reference the QuickSpecs
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Ethernet LAN (RJ-45) ports
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
VGA (D-Sub) ports quantity
1
Performance
Management platform
HPE iLO Standard with intelligent provisioning (embedded), and HPE Compute Ops Management (optional subscription available)
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Network
LAN controller
Broadcom BCM57416
Ethernet LAN
Yes
Ethernet interface type
10 Gigabit Ethernet
Power
Power supply type
2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Redundant power supply (RPS) support
Yes
Number of redundant power supplies installed
1
Redundant power supply (RPS) support
Yes
Power supply
2000 W
Number of redundant power supplies installed
1
Number of main power supplies
1
Design
Chassis type
Rack (2U)
Other features
Standard fans
6x High Performance Fan
Storage drive type
None ship standard, 8 SFF supported
Security features
HPE TPM 2.0 standard on motherboard. Optional locking Bezel Kit, Intrusion Detection Kit. For full security features refer to the QuickSpecs.
Number of processors supported
1
Weight & dimensions
Width
732.5 mm
Depth
448 mm
Height
87.5 mm
Width
732.5 mm
Depth
448 mm
Height
87.5 mm
